Austa 3.6kW Hybrid Inverter | KS

3.6kW Hybrid Inverter...

This compact and stylish single-phase hybrid inverter is the beginning of your sustainable energy journey!

Hybrid inverters can operate in numerous ways depending on the application. Predominantly, a single-phase inverter takes DC electricity which is supplied through the solar panels and converts this into AC electricity which is then distributed across a single-phase supply.

Hybrid inverters are a combination of off-grid/ on-grid and battery storage which you can connect up to 3.6kw to the grid with no permission required.

You can connect them to on-grid and off-grid sources.

With easy Wi-Fi configurations via the app and data checks on the display screen and app, this hybrid inverter is quick and efficient for any residential home.

The design is compact and elegant with minimal noise and integrated diecasting technology as well as quick plug terminals for easy installation!

Single-phase inverters are commonly used in new homes and small businesses with the electricity transported along an active and neutral wire.

Using a single-phase inverter in your home or business will effectively use the energy that has been generated by your solar panels and will significantly reduce the cost of your energy bills!

Additional information:

• When you need more power than one inverter can provide, you can connect two or more inverters in parallel. This increases the total wattage that the inverters can produce and gives you added redundancy in case of a failure.

Controlling the inverter and monitoring its operation:

• Inverter control is made easier with an innovative product, for example with an LCD display showing power, voltage, DC and AC current, as well as daily, monthly and yearly energy production.

• It is most convenient to do it from a computer, especially a tablet or smartphone. Monitor the installation as often as possible as you will begin to notice that something is wrong with it. Contact your installer immediately if anything should occur.

• An inverter synchronized with the grid (grid, hybrid) counts the energy produced by the solar panels, and at the same time reads the current drawn from the power grid. In this way, you can know the difference between the electricity you use for your own needs and the electricity that you feed into the grid. You can compare these data in different cycles (e.g. day, week, month, year).

• IP65 rated for extra weather protection.

• The warranty is 5 years for the hybrid inverter.

Dimensions:

Width: 534mm

Height: 418mm

Depth: 210mm

Weight: 27kg

Operating Temperature Range: -30 - 60 degrees Celcius

Battery Type: Lithium Battery

Battery Voltage Range (V): 85-465

Max. Charge/Discharge Current (A): 30/30
